Introduction
DCFM series DC/DC power module is specially designed for hydrogen fuel cell bicycle, tricycle and portable power generation. Power range of this product line is from 200 W to 6 kW. They are suitable for low voltage application under 170 V
Specs
| Characteristics | Buck‑boost (No special relationship between V‑in and V‑out) | ||
| Model type | DCFM‑UD‑LT‑30 | DCFM‑UD‑0049‑60 | DCFM‑UD‑0049‑120 |
| Maximum continuous current | 30 A | 60 A | 120 A |
| Power range | 200 W~600 W | 1 kW~3 kW | 3 kW~5 kW |
| Input voltage range | 10 V~57 V | 10 V~130 V | 10 V~170 V |
| Output voltage range | 10 V~57 V | 10 V~110 V | 10 V~110 V |
| Control mode | Input CC‑output CV, output CV | ||
| Efficiency | Depends on buck or boost voltage ratio | ||
| Communication, power supply | CAN2.0B，9V‑36VIsolated CAN 2.0B, 9V‑36V | ||
| Volume (mm) | 115×70×46 | 124×115×51 | 205×125×60 |
| Weight (kg) | 0.3 | 0.65 | 1.8 |
| Cooling, protection class | Air‑cooled, IP67 enclosure can be customized | ||
Features
High Power Density
Full-Sic design, enabling product miniaturization.
Outstanding Reliability
Automotive-grade design with IP67 protection rating; EMC complies with Class-B safety standards.
Excellent Energy Efficiency
Full-load efficiency reaches 96%-98%.
Long Service Life
Designed service life over 10 years.
Strong Compatibility
Wide constant-power voltage range, suitable for fast-charging, energy storage, industrial DC power supply and other scenarios.
Application
Computing‑power Data Center
Fuel‑cell EV Charger
Hydrogen Fuel Cell Bicycle Tricycle
Hydrogen Fuel Cell Forklift
Hydrogen Fuel Cell UAV
